DATOUBOSS 48V 6.2kW 16kWh Solar Home Storage Backup Off Grid Kit 314Ah LiFePO4(210A BMS) + 6200W Solar Hybrid Inverter 120A MPPT, 48VDC to 230VAC, 8500W PV Input, 27A, BMS Protection, Lightning Protection, for Solar Home RV Energy Storage
-
5-Year Warranty
Long-term protection, worry-free use -
30-Day Free Returns
Easy returns within 30 days -
No VAT
No additional value-added tax is required. -
Free Shipping
Fast and free delivery to your door
Frequently Bought Together
Order in the next [hours] hours [mins] minutes to get it between and
DATOUBOSS 48V 6.2kW 16kWh Solar Home Storage Backup Off Grid Kit 314Ah LiFePO4(210A BMS) + 6200W Solar Hybrid Inverter 120A MPPT, 48VDC to 230VAC, 8500W PV Input, 27A, BMS Protection, Lightning Protection, for Solar Home RV Energy Storage
DATOUBOSS 48V 6.2kW 16kWh Solar Home Storage Backup Off Grid Kit 314Ah LiFePO4(210A BMS) + 6200W Solar Hybrid Inverter 120A MPPT, 48VDC to 230VAC, 8500W PV Input, 27A, BMS Protection, Lightning Protection, for Solar Home RV Energy Storage
| Category | Details |
|---|---|
| Total Energy | 16.07 kWh |
| Nominal Operating Voltage | 51.2V |
| Single Battery Capacity | 314Ah |
| Weight | 113 kg |
| Dimensions (L×W×H) | 453 × 260 × 879 mm |
| Internal Resistance | ≤ 13.9mΩ |
| Standard Input Current | 210A |
| Standard Output Current | 157A (Max 210A) |
| Overcharge Protection | 58.4V |
| Over-discharge Protection | 43.2V |
| Discharge Cut-off Voltage | 40V |
| Overcurrent Protection (Charging) | 215A |
| Overcurrent Protection (Discharging) | 215A |
| Short Circuit Protection | Yes (via load removal and charge disconnection) |
| Power Delivery Rate | 40% to 60% |
| High-temperature Charging Protection | 55°C |
| High-temperature Charging Recovery | 50°C |
| Low-temperature Charging Protection | 0°C |
| Low-temperature Charging Recovery | 5°C |
| High-temperature Discharge Protection | 55°C |
| High-temperature Discharge Recovery | 50°C |
| Low-temperature Discharge Protection | -20°C |
| Low-temperature Discharge Recovery | -15°C |
| Cycle Life (25°C, 70% SOH) | ≥ 8000 cycles |
| Cycle Life (45°C, 70% SOH) | ≥ 3000 cycles |
| Ingress Protection | IP20 |
| Communication Protocols | RS232, RS485, CAN |
| Power Status LED | OFF (Power Off), Flash 1 (Static state), Flash 3 (Charging/Discharging) |
| Alarm Indicators | Flash based on specific issues like over-voltage, over-current, temperature faults |
| State of Charge (SOC) | LED indicator varies from OFF to fully ON, indicating charge level from 0% to 100% |
| Passive Equalization | Ensures balanced charge across cells |
| Power Consumption when Off | ≤ 300μA |
| Alarm and Reset Functionality | For over-voltage, over-current, and other fault conditions |
| Recommended Installation | Vertical mounting, sturdy surface, temperature between 0°C and 55°C |
| Professional Installation Recommended | Due to high electrical requirements |
